Detalles del producto
Lugar de origen: Porcelana
Nombre de la marca: LINK-PP
Certificación: UL,RoHS,Reach,ISO
Número de modelo: F5-UPG-SFP+LR-R
Pago y términos de envío
Cantidad de orden mínima: 1/10/100 piezas
Precio: $ 6.69
Detalles de empaquetado: Bolsa antiestática individual + bandeja protectora de plástico + caja exterior
Tiempo de entrega: Barcos en el plazo de 15 días
Condiciones de pago: LC, D/A, D/P, T/T, Western Union
Capacidad de la fuente: 1kk/Month
Número de pieza: |
F5-UPG-SFP+LR-R |
Velocidad de datos: |
10 Gbps |
Tipo de fibra: |
Modo único |
Distancia: |
Hasta 10 km |
Serie: |
10GBASE-LR |
Consumo de energía: |
de energía < 1,5 W |
Número de pieza: |
F5-UPG-SFP+LR-R |
Velocidad de datos: |
10 Gbps |
Tipo de fibra: |
Modo único |
Distancia: |
Hasta 10 km |
Serie: |
10GBASE-LR |
Consumo de energía: |
de energía < 1,5 W |
The F5-UPG-SFP+LR-R is a 10GBASE-LR SFP+ optical transceiver module designed for long-distance single-mode fiber (SMF) transmission up to 10 km, operating at 1310 nm wavelength. It is fully compatible with F5 BIG-IP application delivery controllers (ADCs) and enterprise-grade networking equipment, delivering high reliability, seamless integration, and carrier-class performance.
This module is widely deployed in:
Pain Point: Many network engineers face compatibility risks when deploying third-party transceivers, leading to module rejection, link instability, firmware alarms, and loss of official vendor support.
Solution: F5-UPG-SFP+LR-R is fully coded and certified for F5 BIG-IP platforms, ensuring plug-and-play deployment, zero compatibility risk, no firmware conflict, and full technical support eligibility.
Pain Point: Standard copper and short-range optical modules cannot meet cross-building or campus-level transmission distances.
Solution: With 10 km reach over single-mode fiber, F5-UPG-SFP+LR-R enables reliable building-to-building connectivity, data center interconnection (DCI), and Metro Ethernet deployments.
Pain Point: Unstable optical links cause packet loss, service interruption, SLA violations, and costly troubleshooting.
Solution: Built using industrial-grade laser components and advanced optical calibration, this module ensures ultra-low bit error rate (BER), stable optical power output, and long operational lifetime.
| Parameter | Specification |
|---|---|
| Part Number | F5-UPG-SFP+LR-R |
| Data Rate | 10 Gbps |
| Standard | IEEE 802.3ae 10GBASE-LR |
| Wavelength | 1310 nm |
| Fiber Type | Single Mode Fiber (SMF) |
| Max Distance | 10 km |
| Connector | Duplex LC |
| Laser Type | DFB |
| Receiver | PIN |
| DOM/DDM | Supported |
| Power Consumption | < 1.5W |
| Operating Temperature | 0 ~ 70°C |
This transceiver is fully compatible with major F5 BIG-IP hardware appliances, including but not limited to:
| Feature | LR (F5-UPG-SFP+LR-R) | SR |
|---|---|---|
| Fiber Type | Single Mode | Multi Mode |
| Distance | Up to 10 km | Up to 300 m |
| Typical Use | Backbone, DCI, Campus | In-rack, short links |
| Cost Efficiency | Better for long links | Best for short links |
Choose LR modules when distance exceeds 300 meters or when using single-mode fiber infrastructure.
Yes. The module supports hot-plugging, enabling replacement without network interruption.
This module is firmware-coded specifically for F5 platforms. For other vendors, use vendor-coded versions.
Yes, it supports real-time optical diagnostics monitoring.
The F5-UPG-SFP+LR-R 10G SFP+ LR transceiver is the ideal choice for long-distance, high-reliability optical connectivity in F5 BIG-IP environments. With full compatibility, enterprise-grade stability, and carrier-class performance, it ensures maximum uptime, optimal signal integrity, and low total cost of ownership (TCO).
