Detalles del producto
Lugar de origen: Cantón, China
Nombre de la marca: LINK-PP
Certificación: IEEE 802.3ae, RoHS, IEC 60825-1
Número de modelo: AFCT-701SDZ
Pago y términos de envío
Cantidad de orden mínima: 1 pieza, 10 piezas
Precio: $3.1-$5
Detalles de empaquetado: El rollo
Tiempo de entrega: 2-3 días
Condiciones de pago: LC, D/A, D/P, T/T, Western Union
Capacidad de la fuente: 5kk/mes
Longitud de onda: |
1310nm |
Tarifa de datos: |
10 Gbps |
Distancia de transmisión: |
10 km (10GBASE-LR) |
Consumo de energía: |
850 mW |
Conector: |
Dúplex LC |
Interfaz de diagnóstico: |
SFF-8472 DOM |
Tipo de láser: |
DFB (comentarios distribuidos) |
Tipo de receptor: |
PIN (Fotodiodo) |
Longitud de onda: |
1310nm |
Tarifa de datos: |
10 Gbps |
Distancia de transmisión: |
10 km (10GBASE-LR) |
Consumo de energía: |
850 mW |
Conector: |
Dúplex LC |
Interfaz de diagnóstico: |
SFF-8472 DOM |
Tipo de láser: |
DFB (comentarios distribuidos) |
Tipo de receptor: |
PIN (Fotodiodo) |
The Avago AFCT-701SDZ is a high-performance 10Gb Ethernet SFP+ transceiver designed to meet the 10GBASE-LR standard. Utilizing 1310nm DFB laser and PIN detector technology, it delivers reliable long-range connectivity. Engineered for high-density applications, this transceiver adheres to enhanced SFP+ specifications developed by the SFF Committee. The AFCT-701SDZ supports low power consumption with 850mW typical dissipation and features a digital diagnostic interface for real-time monitoring and predictive failure identification, ensuring consistent system uptime and performance.
| Parameter | Minimum | Typical | Maximum | Units | Notes |
|---|---|---|---|---|---|
| Transmitter | |||||
| Laser OMA output power | -5.2 | - | - | dBm | 1 |
| Laser mean output power | -8.2 | 0.5 | - | dBm | 1 |
| Laser off power | - | - | -30 | dBm | 1 |
| Extinction ratio | 3.5 | - | - | dB | 1 |
| Transmitter and dispersion penalty (TDP) | - | - | 3.2 | dB | 1 |
| Center Wavelength | 1260 | - | 1355 | nm | 1 |
| Side Mode Suppression Ratio - SMSR | 30 | - | - | dB | 1 |
| RIN12OMA | - | - | -128 | dB/Hz | 1 |
| Optical Return Loss Tolerance | - | - | 12 | dB | 1 |
| Transmitter Output Eye Mask | - | - | - | - | 1, See Figure 4b |
| Receiver | |||||
| Stressed sensitivity (OMA) | - | - | -10.3 | dBm | 1 |
| Receive sensitivity (OMA) | - | - | -12.6 | dBm | 1 |
| Receive Power (Pave) Overload | - | - | 0.5 | dBm | 1 |
| Reflectance | - | - | -12 | dB | 1 |
| Center Wavelength | 1260 | - | 1355 | nm | 1 |
| RX_LOS (OMA) De-Assert | - | - | -17 | dBm | 3 |
| RX_LOS (OMA) Assert | - | - | -30 | dBm | 3 |
| RX_LOS (OMA) Hysteresis | 0.5 | - | - | dB | - |
| Vertical eye closure penalty | - | - | 2.2 | dB | 2 |
| Stressed eye jitter | - | - | 0.3 | UI p-p | 2 |
